Product Features
• Programmable Transmit Power: The radio's transmit power level can be programmed up to +29 dBm.
• Programmable Duty Cycle: (GPS synchronized frames) The AF-5XHD allows configuration of asymmetric TX and RX duty cycles. TX ratios include 25%, 33%, 50%, 66.7%, and 75%.
• Configurable GPS Synchronization: The AF-5XHD offers configurable support for 2, 2.5, 4, and 5 ms frames. Timing is compatible with all other synchronous systems.
• Split TX and RX Frequency: The radio can operate on different frequencies for TX and RX, allowing great flexibility for interference avoidance.
• Split TX and RX Channel Bandwidth: Support for different channel bandwidths for TX and RX allows users to scale required data capacity more efficiently
• Adaptive Modulation up to 1024QAM: Adaptive modulation rates of up to 1024QAM (4096QAM with targeted upgrade) are supported.
• Dual Redundant Gigabit Ethernet Ports with PoE: The AF-5XHD has two Gigabit Ethernet ports that can be used to provide redundant PoE power.
• OFDM and OFDMA Support: The radio offers flexible scheduling for 2, 4, or 8 sub channels.
• Bluetooth Wireless Configuration: Use the built-in Bluetooth interface for wireless configuration.
• Align Lock™ Antenna Aiming Guard This alerts the user when the radio or antenna aiming is changed due to tampering, impact, or storm damage.
• User-Configurable Interference Mitigation Three user-selectable profiles support both high interference and greenfield deployments for robust, optimal performance.
• Redundant Images for Fail-Safe Configuration Creation of backup firmware images ensures fail-safe configuration and enhances reliability.
• Persistent Spectrum Analysis with Dedicated RX Perform real-time spectral analysis for the full band on live links without interrupting the link operation.
• Wide Voltage Range, Enhanced Surge Protection The AF-5XHD has an operating voltage range of 24 48VDC and provides enhanced surge protection.
AIRFIBER
| Dimensions | 224 x 82 x 48 mm (8.82 x 3.23 x 1.89") |
| Weight | 0.35 kg (0.77 lb) |
| GPS | External, Magnetic Base |
| Operating Frequency |
5150-5250MHz 5740-5850MHz |
| Power Supply | 24V, 1A PoE Gigabit Adapter (Included) |
| Power Method | Dual Passive Power over Ethernet |
| Maximum Power Consumption | 12W |
| Supported Voltage Range | 20-50VDC |
| Mounting |
airFiber X Mount (Rocket Mount Compatible) GPS Pole Mount (Included) |
| Certifications | FCC |
| Operating Temperature | -40 to 55° C (-40 to 131° F) |
INTERFACE
| Data Port | (1) 10/100/1000 Ethernet Port |
| Configuration Port | (1) 10/100/1000 Ethernet Port |
SYSTEM
| Processor | LTU IC |
| Maximum Throughput | 1.3+ Gbps |
| Maximum Range | 200+ km (Throughput and range values may vary depending on the environmental conditions) |
| Encryption | 128-bit AES |
| Operating System | airOS F |
RADIO FREQUENCY
| Max TX Power | 29 dBm (Dependent on Regulatory Region) |
| Frequency Accuracy |
± 2.5 ppm without GPS Synchronization ± 0.2 ppm with GPS Synchronization |
| Channel Bandwidth | 10/20/30/40/50/60/80/100 MHz Selectable |
