| Recording Bandwidth | Inputs |
 16Mbps |
| out | 216Mbps | |
| Analog video-input | 32CH inputs | |
| Live | IP Video Input | 4ch |
| Composite Video Input | up to 36ch (Analog video + IP video) | |
| Performance | ||
| Recording and Playback | Compression |
 Audio: G.711aVideo : H.264/H.265 |
| Display resolution |
Analog : 5MP-Lite:20fps 4MP-Lite:30 fps 1080P/720P/960H:30fps IP : 5MP/4MP/3MP1080P/720P |
|
| Speed |
Analog : 5MP-Lite:15fps (each ch) 4MP-Lite:20fps(each ch) 1080P:15fps(each ch) 720P:PAL:25fps(each ch)/NTSC::30fps(each ch) IP : PAL:25fps(each ch)/NTSC: 30fps(each ch) |
|
| AI |
PID - Perimeter Intrusion Detection LCD - Line Crossing Detection PD&VD - Human&Vehicle Detection FD - Face Detection FR - Face Recognition |
|
| Event | MD(Sensitivity Level 1~8) | |
| Videlo loss | ||
|
Beep, Email, Push notification to Mobile APP |
||
| Playback function | Fast forward / backward (2x, 4x, 8x,16x) | |
| Slow forward (1/2x, 1/4x, 1/8x,1/16x) | ||
| Playback |
5MP-lite: 240fps （Max 16CH playback ） 4MP-lite: 320fps （Max 16CH playback） 1080P: 480fps（Max 16CH playback） 720P:960fps（Max 16CH playback |
|
| UI/Monitoring | Local | UI5.0 |
| WEB |
IE10/11 Safari V12.1 above Firefox V.52 above Google chrome V.57 above Edge V.79 above |
|
| Mobile viewer | Rxcamview | |
| Push N/Atification | yes | |
| Interface | ||
| P/W Reset | Factory Reset : Press 10 seconds | |
| Monitors | BNC | 1 (704*576) |
| VGA | 1（1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 ） | |
| HDMI | 1（1024*768,1280*720,1280*1024,1440*900,1920*1080,2560*1440(2K),3840*2160(4K)） | |
| Ethernet | 2 RJ45 100/1000 Base-T | |
| USB |
USB2.0*1(front) USB3.0*1+(rear) |
|
| Audio | 8 in / 1 out | |
| HDD | 4 SATA HDD, Up to 10 TB capacity for each disk | |
| ESATA | 1 | |
| RS485 | 1 | |
| Alarm Input/out | 16 in /1 out | |
| General | ||
| OSD Language | English/French/Spanish/Portuguese/German/Italian/Greek/Danish/Finnish/Russia/Hebrew/Turkish/Bulgarian/Arabic/Korean/Japanese/Thai/Hindi/Romanian/Dutch/Polish | |
| Mechanical design | Dimension (WxDxH) | 380*340*50mm |
| Electrical | Input Voltage/Current | DC12V/5A |
| Power consumption (excluding hard disk) | 21W | |
| Environmental | Operating Temperature/Humidity |
Temperature : -10°C~+50°C (14°F ~ 122°F) Humidity : Less than 90%RH |
