Record Bandwidth IP Cam Inputs
32Mbps ~48Mbps
Analog channel and digital channel can be converted
Encoding performance and decoding performance cannot be converted
Total decoding performance 1080P 120fps
Recording Resolution out
96Mbps
Display resolution
Analog : 5MP-Lite:20fps
4MP-Lite:30 fps
1080P/720P/960H:30fps
IP : 5MP/4MP/1080P/720P
Single channel preview up to 2MP 30 fps
multi-channel preview only substream
Speed
Analog : 5MP-Lite:12fps (each ch)
4MP-Lite:16fps(each ch)
1080P:15fps(each ch)
720P:PAL:25fps(each ch)/NTSC:30fps(each ch)
IP : PAL:25fps(each ch)/NTSC: 30fps(each ch)
The sub-stream frame rate is less than the preview frame
H.264 performance is about 20% lower than H.265
Playback
1080P:120fps
Max8CH playback
Internal HDD
1 SATA HDD, up to 8TB default ( (Design reserved 2HDD or 1HDD+1ESATA),
Dimension(W×D×H)
300X227X53mm
Operating Temperature/Humidity
Temperature : 0°C~+40°C (32°F ~ 104°F)
Humidity : Less than 90%RH
| 1 | AP-D8116HR-NS-T | Download |
|---|
